MH100 Polyester Strapping Head

The FROMM M100 Steel Strapping Head is a hydraulic powered, fast and efficient solution for steel strap 9.5mm to 20mm in width in heavy duty industrial applications.

The M100 is designed for continuous and shift operations, capable of tension up to 9000N and offering high efficiency for general baling and strapping of unitised products such as timber, metal or building products.

Request a quote

Two Year Warranty

Simulation Testing

5 Star Rated

Environmentally Friendly

Features

High strap tension to 9000N adjustable
High seal efficiency to 80%
Tension system with integrated floating design
Sealless strap joint
Modular feeding and sealing system
Low wear on punching tools
Hydraulically powered and controlled

Benefits

Low maintenance
Long service intervals
Proven "FROMM" technology
Can be retrofitted into other systems
Low cost of spare parts
Excellent seal efficiency

Options

Dispenser for jumbo-coils
Sword
Machine with travel facility
Integrated bunker feed system
Edge protection system
Vertical press systems up to 20 KN press force
Conveying System

Technical Specification

Suitable Strapping Qualities

Regular duty steel (Uniflex) up to 850 N High tensile steel (Ultraflex) up to 1100 N

Strapping Dimensions

Width: 9.5 – 20.0 mm Thickness: 0.50 – 0.80 mm

Strapping Head Type

Hydraulic

Sealing Method

Sealless joint

Seal Strength

Up to 80% (dependent on strap quality)

Strap Tention

Up to 9000 N, adjustable

Feed / Retract Speed

2 metres / second, adjustable

Consumption

1.1 KW

Package Size

Min. W300 x H20 mm Max. W2500 x H3000 mm

Power

Hydraulic, pressure up to 185 bar Flow 10l/min

Control Voltage

24 V DC

Dimension

L 440 x W 220 x H 450 mm

Weight

67 kg

Download library

Steel Strapping Heads Brochure

Download

FROMM’s steel strap options are engineered with durability and strength in mind while also considering environmental footprint. Steel, being one of the most recyclable materials, offers long-term sustainability. Our steel straps can be melted down and reused repeatedly without losing structural integrity. By choosing steel strapping, companies can secure their products while minimizing environmental impact by reducing the need for new raw materials.

Reuse: Steel strapping is incredibly strong, particularly in closed-loop or internal handling systems. Its ability to maintain strength and durability over time makes it an excellent choice for industries looking to maximize product lifecycle.

Reduce: FROMM’s steel strapping is available in regular duty and high tensile varieties, meaning businesses can choose the exact strength needed without overusing materials. This helps reduce the total amount of steel required per application, optimizing resource efficiency.

Recycle: Steel is one of the most recyclable materials on the planet. FROMM’s steel strapping can be recycled indefinitely without losing its properties, making it a sustainable choice for industries. Recycling steel reduces the need for virgin raw materials and supports energy conservation by lowering the carbon footprint associated with steel production.
